Saab J32 Lansen Low-poly 3D model

Description

Model based on the Saab J32 Lansen airplane. With two skins from the Swedish Air Force, and one from the Portuguese Air Force (Fictional).

PIPELINE:

• Highpoly / Lowpoly / UVs made in Blender;
• Bakes in Marmoset Toolbag;
• Textures in Substance Painter and GIMP.

TOPOLOGY (Lowpoly - LP):

• fuselagePanels_frontMiddle: 32.485 tris;
• fuselagePanels_rear: 17.356 tris;
• wingPanels: 14.814 tris;
• details: 116.432 tris;
• cockpitPanels: 39.158 tris;
• cockpitDecalPlanes: 402 tris;
• cockpitInstruments: 23.554 tris;

• cockpitExtras: 56.450 tris.

• Total: 300.651 tris.

TEXTURES:

• Model has 8 texture sets:
  • fuselagePanels_frontMiddle: 6,523 px/cm (4K);
  • fuselagePanels_rear: 6,753 px/cm (4K);
  • wingPanels: 6,012 px/cm (4K);
  • details: 6,356 px/cm (4K);
  • cockpitPanels: 29,365 px/cm (4K);
  • textPlanes: 22,615 px/cm (512x512);
  • cockpitInstruments: 23,864 px/cm (4K);
  • cockpitExtras: 10,640 px/cm (4K).
• Model is completely UV-unwraped (mixed method);
• Metallic/Rough PBR workflow;
• 4K/512x512 textures (in PNG format).

NOTES:

• No Ngons, just Quads and Tris;
• All geometry is correctly organized and named;
• Real world scale 1:1;
• Units of measurement: Milimeters;
• Basemesh geometry (with modifiers) in separate .blend file;
• Highpoly geometry (Decimated) in separate .blend file;
• FBX file: Millimeters / Z-Up / X-Forward / Triangulated;
• OBJ file: Millimeters / Z-Up / X-Forward / Triangulated;

3D MODEL SPECIFICATIONS:

• 153.756 Polygons;
• 170.615 Vertices;
• Polygonal Quads / Tris Geometry;
• Textures;
• UV Mapped;
• Mixed Unwrapped UVs.
